神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (05-002) - MIRROR INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
946 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN52C00002F3 | [1] | MIRROR | KOBINSTAL |
| 3. | YN02C01762P1 | [1] | BRACKET | KOB |
| 4. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 5. | ZW16X12000 | [2] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 6. | R16T0137D1 | [2] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 0.9mm |
| 7. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 8. | 2456R351 | [1] | MIRROR | KOB |
| 9. | YN02C01802P1 | [1] | STAY | KOBStay |
| 10. | YN02C01121P1 | [1] | MIRROR | KOB |
| 11. | ZM46C05016 | [3] | BOLT,Phillip, M5 x 0.8 x 15mm | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| 12. | YT50C01077P1 | [1] | BLOCK | KOB |
| 13. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 14. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
