| 1. |
76082156
|
[4] |
ISOLATOR
|
CAS
Molded Ring
|
| 2. |
BN302284
|
[4] |
WASHER,23.88mm ID x 98.55mm OD x 6.35mm Thk
|
BN
Rebound, 3.88 od x .94 id x .25
|
| 3. |
BN321660
|
[1] |
TRANSFER UNIT
|
BN
Case, Fabco 2 Wheel Superseded by part number: 84377090
|
| 3. |
BN321660R
|
[1] |
REMAN-HOUSING
|
MKT
Case, Transfer, 2 WHL Superseded by part number: 84377090R
|
| 3. |
BN321660C
|
[1] |
CORE-HOUSING
|
MKT
Return Part Number, Housing, Transfer Case
|
| 3. |
84377090R
|
[1] |
REMAN-TRANSMISSION
|
RAC
FLX3010, FLX3510, Reman For New P/N's BN321660 & 84377090
|
| 3. |
84377090C
|
[1] |
CORE-TRANSMISSION
|
RAC
Return Part Number
|
| 3A. |
217-1164
|
[1] |
TEE,3/4" - 14 NPT x 3/4" - 14 NPT x 3/4" - 14 NPT
|
CAS
Located On The Side Of The Aux Transmission
|
| 4. |
BN322517
|
[2] |
YOKE
|
BN
SPL 170, 1.998-38
|
| 5. |
BN323165
|
[1] |
PLATE
|
BN
Auxiliary Superseded by part number: 84603660
|
| 6. |
87269619
|
[1] |
PLATE
|
BN
Auxiliary Hanger, Start Serial: 6700
|
| 6. |
BN323168
|
[1] |
SUPPORT
|
BN
Aux Rear Plate Superseded by part number: 87269619
|
| 7. |
413-1020
|
[8] |
BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 280319
|
| 8. |
87023159
|
[8] |
WASHER,0.64" ID x 1.05" OD x 0.13" Thk
|
SAS
41/64" x 1.047" x .134", HDN
|
| 9. |
827-22120
|
[4] |
BOLT,Hex, M22 x 2.5 x 120mm, Cl 10.9
|
FAR
Superseded by part number: 87342024
|
| 10. |
87344025
|
[4] |
NUT,Prev Torque, M22, 2.5 Pitch, Cl 10, DOR
|
BN
|
| 11. |
896-11022
|
[4] |
WASHER,24mm ID x 44mm OD x 4mm Thk
|
CAS
Superseded by part number: 76088905
|
| 12. |
NS
|
[1] |
NOT SERVICED
|
BAS
Group, Auxiliary Transmission Pneumatic, Start Serial: 6700
|
| 12. |
BN324357
|
[1] |
Group, Auxiliary Transmission Pneumatic
|
|
| 13. |
71100209
|
[1] |
PLUG,Hex Soc, 3/4"-16 ORB
|
BHB
Superseded by part number: 86590562
|
| 14. |
87267035
|
[1] |
COVER
|
BN
Auxiliary Mount
|
| 15. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 16. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 17. |
86625252
|
[8] |
WASHER,10.8mm ID x 21.5mm OD x 2.5mm Thk
|
FAR
|
| 18. |
84246629
|
[1] |
GUARD
|
BN
Auxillary Trans.
|
