| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN25C00003F4 | [1] | GUARD | KOBCAB Superseded by part number: YN25C01006P1, ZS18C08014, 83990583, YN25C01012P1, YN25C01003P1, LC21C01139D3, ZW16X08000, 2420R220D25, YN25C01007P2, YN25C01010P1, ZW16H08000, YN25C01014P1, HY25X10027G1, YN25C01011P1, YN25C01009P2, YM25C01002P1, YN25C01005P1, LC21C01139D2, YN25C01008P2, YN25C01004P1, YN25C01002P1, ZM22C08020, YN25C01001P1, YM25C01004P1, YM25C01003P1, YM25C01006P1, ZS18C08020 |
| A1. | YN25C01010P1 | [1] | GUARD | KOB |
| A2. | YN25C01012P1 | [1] | GUARD | KOB |
| A3. | YN25C01011P1 | [1] | GUARD | KOB |
| A4. | YN25C01007P2 | [1] | GUARD | KOB |
| A5. | YN25C01008P2 | [1] | GUARD | KOB |
| A6. | YN25C01009P2 | [1] | GUARD | KOB |
| A7. | YN25C01006P1 | [1] | GUARD | KOB |
| A8. | YN25C01005P1 | [1] | GUARD | KOB |
| A9. | YN25C01004P1 | [1] | GUARD | KOB |
| A10. | YN25C01003P1 | [1] | GUARD | KOB |
| A11. | YN25C01002P1 | [1] | GUARD | KOB |
| A12. | YN25C01001P1 | [1] | GUARD | KOB |
| A13. | ZM22C08020 | [2] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| A14. | ZS18C08014 | [2] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| A15. | ZW26X08000 | [12] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| A16. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| A17. | YN25C01014P1 | [14] | PLATE | KOB |
| A25. | YM25C01002P1 | [1] | BOX | KOB |
| A26. | YM25C01003P1 | [1] | BOX | KOB |
| A27. | YM25C01005F1 | [1] | SUPPORT ASSY | |
| A28. | YM25C01007F1 | [1] | SUPPORT ASSY | |
| A29. | 2420R220D25 | [2] | BOLT,Wing, M8 x 25mm | KOBWing, M08x25mm Long |
| A30. | HY25X10027G1 | [2] | WASHER,10mm ID x 27mm OD x 3.2mm Thk | KOBID 10 x OD 27 x Th 3.2mm |
| A31. | ZS18C08020 | [10] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| A32. | ZW16H08000 | [10] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| . . | YN22TU0003F2 | [1] | PLATE | KOBNAME PLATE INSTAL VANDAL GUARDS |
| B1. | YN20TU1004P1 | [1] | LABEL | KOB |
