凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (03-009) - DRIVELINE GROUP, FLX3010 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
664 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN323507
|
[1] |
DRIVEN SHAFT
|
BN
Driveline, 535 Stationary
|
| 2. |
BN323506
|
[1] |
DRIVEN SHAFT
|
BN
Driveline, 535 Slip
|
| 3. |
BN322955
|
[1] |
HANGER
|
BN
Driveline
|
| 4. |
86625255
|
[4] |
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
|
GI
|
| 5. |
374887
|
[2] |
BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8
|
NH
|
| 6. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 7. |
140017
|
[8] |
WASHER,M10 x 20mm OD x 2mm Thk
|
PA
Superseded by part number: 9820489
|
| 8. |
86624978
|
[4] |
BOLT,Hex, M10 x 35mm, Cl 10.9, Full Thd
|
ZED
|
| 9. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
BN326109
|
[6] |
STRAP
|
BN
Yoke, SPL 170
|
| 11. |
BN326110
|
[12] |
BOLT
|
BN
Yoke Strap, SPL 170 Driveline Service Parts
|
