神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (02-005) - IDLER ADJUSTMENT ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
614 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM54D00003F2 | [1] | IDLER | KOB |
| 1. | YN70V00006P1 | [1] | GREASE | KOB |
| 2. | YN54D01041P1 | [1] | BRACKET | KOB Superseded by part number: YN54D01051P1 |
| 3. | YN54D01038P1 | [1] | NUT | KOBM52x3.0mm |
| 4. | ZP26D08080 | [1] | PIN | KOBRoll -- OD 08 x 80mm Long |
| 6. | 2439P177 | [1] | PISTON | KOB |
| 7. | YN54D01042P1 | [1] | COLLAR | KOB |
| 8. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 9. | 2418U130D35 | [1] | PACKING | KOBOIL SEAL |
| 10. | 2419T4748 | [2] | PIN | KOB Superseded by part number: LQ54D01023P1 |
| 11. | YN54D01029P1 | [1] | COVER | KOB |
| 12. | YM54D01003P1 | [1] | SPRING | KOB Superseded by part number: YM54D01003P2 |
