神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (02-006) - LOWER ROLLER ASSEMBLY, P/N YN64D00005F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
277 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN64D00005F1 | [1] | ROLLER ASSY, TRACK | |
| 1. | YF64D00001F1 | [14] | ROLLER | KOBTRACK Superseded by part number: LQ64D00054F1 |
| 1-1. | YN64D01021P1 | [1] | ROLLER | KOBOD Ø185 x 220mm Long |
| 1-2. | YN64D01041P1 | [2] | COLLAR | KOB |
| 1-3. | YN64D01042P1 | [1] | SHAFT | KOBOD 65 x 338mm Long Superseded by part number: LQ64D01028P1 |
| 1-4. | 2405P489 | [2] | BUSHING,66mm ID x 87mm OD x 64.5mm L | KOBID 65 x OD 69 x 60mm Long |
| 1-5. | YN64D01043P1 | [2] | PIN | KOBOD 16 x 76mm Long |
| 1-6. | 2445R451F1 | [2] | SEAL,90mm ID x 114.45mm OD x 33mm Thk | KOBSEAL, FLOATING Superseded by part number: 2445R441F1 |
| 1-7. | ZD11G06000 | [2] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm | KOBID 59.40 ± 0.61 x OD 65mm |
| 1-8. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 2. | 2420P1580D4 | [56] | BOLT,Hex, M18 x 1.5 x 80mm | KOBM18x1.50x80mm |
