凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (08-006) - HEADLIGHT GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
910 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
365842A1
|
[1] |
HEADLAMP
|
CAS
Left, With Work Lamp
|
| 3. |
365841A1
|
[1] |
HEADLAMP
|
CAS
Right, With Work Lamp
|
| 4. |
BN326093
|
[1] |
MOUNTING PLATE
|
BN
Center Adjuster
|
| 5. |
BN326090
|
[1] |
MOUNTING PLATE
|
BN
Light Adjuster, CS
|
| 6. |
BN326091
|
[1] |
MOUNTING PLATE
|
BN
Light Adjuster, RS
|
| 16. |
281-54712
|
[6] |
SCREW,Hex Wshr Hd, 1/4" - 20 x 3/4"
|
CAS
Superseded by part number: 87343659
|
| 17. |
87343624
|
[9] |
HEX SOC SCREW,M5 x 45mm, Cl 8.8, Full Thd
|
BN
M5 X 45, 8.8 Hex Socket
|
| 18. |
342132A1
|
[9] |
SPRING
|
BN
compression, 9.14 x 1.5 x 25
|
