凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (08-007) - LIGHT GROUP, HID Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
232455A2
|
[1] |
WORK LAMP,HID, 12V, 35W, Clear
|
CAS
center, HID - Includes Bulb (NSS due to cost)
|
| 2. |
281-54712
|
[4] |
SCREW,Hex Wshr Hd, 1/4" - 20 x 3/4"
|
CAS
Superseded by part number: 87343659
|
| 3. |
333645A1
|
[1] |
CLAMP
|
CAS
HID ballast hold down
|
| 4. |
322332A1
|
[1] |
BALLAST
|
CAS
light, center HID
|
| 5. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 6. |
120104
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
333643A1
|
[1] |
GASKET
|
CAS
foam HID ballast
|
| 8. |
333644A1
|
[1] |
GASKET
|
CAS
foam HID ballast hold down
|
