神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-061[01]) - COMPRESSOR, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
697 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC91V00002F2 | [1] | COMPRESSOR | KOBASSY, AIR Superseded by part number: LC91V00002F3 |
| . . | LC91V00002F3R | [1] | REMAN-A/C COMPRESSOR,W/ Pulley | RACED190LC-6E BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292, SK480LC-6E ASN YS06U0294 - YS06U0621, SK160LC-6E 08/2004 ASN YM03U0523, SK290LC-6E BTW LB04U0298 - LB04U02800, All DYNAMIC ACERA EXCAVATOR, SK250LC-6E DYNAMIC ACERA LL09U0575, LL09U607~, All ASSY, AIR, Reman for New PN LC91V00002F2 |
| . . | LC91V00002F3C | [1] | CORE-A/C COMPRESSOR | RACReturn Number |
| 1. | LC91V00001F1 | [1] | AIRCOND. COMPRESSOR,W/ Pulley | KOBAIR |
| 2. | YX20M01029F2 | [1] | PULLEY ASSY. | KOB Superseded by part number: YX20M01029F4 |
| 2-1. | LC20M01060P1 | [1] | PULLEY | KOBAir Compressor Tension Superseded by part number: YX20M01029F4 |
| 2-2. | 24100U1176S25 | [1] | NUT | KOBM10 |
| 2-3. | 24100U1176S27 | [1] | LOCK WASHER | KOBM08 Superseded by part number: 83990583 |
| 2-4. | 24100U1176S26 | [1] | LOCK WASHER | KOBM10 Superseded by part number: ZW26X10000 |
| 2-5. | 24100U1176S18 | [1] | BOLT | KOB |
| 2-6. | YX20M01029S006 | [1] | SHAFT | KOB |
| 2-7. | 24100U1176S19 | [1] | STOP | KOB |
