神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-002) - COUNTER WEIGHT ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
516 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONCOUNTERWEIGHT ASSY |
| A1. | YM60C00014D1 | [1] | COUNTERWEIGHT | KOB3 Tons (metric) (3.3 Tons) |
| . . | YM60C00016F1 | [1] | COUNTERWEIGHT | KOB |
| B1. | YN60C01140P1 | [2] | FOAM INSULATION | KOB |
| B2. | YM60C01004P1 | [1] | FOAM INSULATION | KOB |
| B3. | YM60C01026P1 | [1] | FOAM INSULATION | KOB |
| B4. | LQ60C01133P1 | [1] | FOAM INSULATION | KOB |
| . . | YM60C00015F1 | [1] | COUNTERWEIGHT | KOB |
| C1. | HS13C24280G1 | [4] | CAPSCREW | KOBSCREW M24x3.0x280mm |
| C2. | HY26Y25054D1 | [4] | WASHER | KOBID 25 x OD 54 x Th 08mm |
| C3. | YN60C01242D1 | [3] | SHIM | KOB80x60x1.6mm |
| C4. | YN60C01242D2 | [3] | SHIM | KOB80x60x2.3mm |
| C5. | YN60C01242D3 | [4] | SHIM | KOB80x60x3.2mm |
| C6. | 2420Z2315 | [2] | PLUG | KOBPLUG, C/W ACCESSORY Superseded by part number: KSP9000-0034 |
| . . | YM80E00003F1 | [1] | Tail Lamp Installation | |
| D1. | YM80S00001F2 | [1] | LAMP | KOBFlashing |
| D2. | YM80S00001F1 | [1] | LAMP | KOBFlashing |
