神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-005[01]) - RADIATOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
565 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM05P00013F1 | [1] | RADIATOR | KOB Superseded by part number: YM05P00013F2 |
| . . | YM05P00013F2 | [1] | RADIATOR | KOB |
| 1. | YN05P00035S001 | [1] | RADIATOR | KOB |
| 2. | YN05P00035S002 | [1] | OIL COOLER | KOB |
| 3. | YM05P00013S003 | [1] | Frame | |
| 4. | YM05P00013S004 | [1] | Frame | |
| 5. | YM05P00013S005 | [1] | Shroud | |
| 6. | YM05P00013S006 | [1] | Plate | |
| 7. | YM05P00013S007 | [2] | Plate | |
| 8. | YN05P00035S009 | [2] | SCREEN | KOB(Debris Screen) |
| 9. | YN05P00029S023 | [1] | PLATE | KOB |
| 10. | YN05P00010S006 | [1] | RADIATOR CAP | KOB Superseded by part number: YN05P00088S032 |
| 11. | ZM22C10025 | [1] | BOLT | KOB |
| 12. | 2452U255S5 | [1] | FLEXIBLE HOSE | KOB |
| 13. | 2452U267S8 | [2] | CLIP | KOB |
| 14. | YN05P00010S007 | [1] | COCK, DRAIN | KOB |
| 15. | 2452U416S6 | [1] | HOSE | KOB |
| 16. | ZS18C08020 | [8] | SCREW,Hex, M8 x 20mm | KOBBOLT |
| 17. | YM05P00013S023 | [2] | INSULATION REPLACES 20 & 21 F2 ONLY | |
| 18. | YN05P00007S016 | [2] | BOLT | KOB |
| 19. | 2452U202S5 | [4] | BOLT | KOBWing |
| 20. | EZ05P00008S008 | [2] | PACKING | KOBPACKING F1 ONLY |
| 21. | YN05P00035S021 | [2] | FOAM INSULATION | KOBF2 ONLY |
| 22. | YB05P00001S022 | [2] | INSULATING PANEL | KOB |
| 23. | YN05P00035S023 | [2] | FOAM INSULATION | KOB |
