凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (06-003) - HYDRAULIC COOLER GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
676 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN324333
|
[1] |
OIL COOLER
|
BN
Transmission/HYD Oil
|
| 2. |
86625263
|
[5] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 3. |
16043224
|
[2] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
|
| 4. |
43127
|
[3] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 5. |
87266238
|
[1] |
HOSE
|
BN
20 x 132"
|
| 6. |
87267719
|
[1] |
HOSE
|
BN
20 x 69"
|
| 7. |
BN305415
|
[2] |
O-RING
|
BN
-20 FFOR Superseded by part number: 9993141
|
