凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (06-004) - TRANSMISSION COOLER LINES GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
725 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
342917A1
|
[1] |
HOSE
|
BN
12 x 80"
|
| 2. |
342918A1
|
[1] |
HOSE
|
BN
12 x 83"
|
| 3. |
BN53894
|
[2] |
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
|
BN
ARP Standard #018 Superseded by part number: 9991976
|
| 4. |
BN302655
|
[2] |
FITTING
|
BN
12 MOR-12 MB
|
| 5. |
515-25317
|
[2] |
CLAMP,1 1/4", Insul, 1/2" Bolt
|
CAS
|
| 6. |
43151
|
[2] |
BOLT,Hex, M12 x 20mm, Cl 8.8, Full Thd
|
NH
|
