神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-020) - HYD LINES, UPPER (ROTATION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
859 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM03H00018F1 | [1] | HYD LINES, UPPER (ROTATION) | |
| 1. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 2. | ZA33F22008 | [2] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 3. | ZS18C10060 | [1] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 4. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 5. | ZW16H12000 | [2] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 6. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 7. | YM03H01064P1 | [1] | SUPPORT | KOB |
| 8. | ZH32X08000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 9. | ZX32M08110 | [1] | HOSE ASSY. | KOBPF1/2, L=1110mm |
| 10. | 2444T2958 | [2] | HYD CONNECTOR | KOBPF1/2, L=41mm(Incls. O-Ring ZD12P01800) |
| 11. | ZA33F18008 | [1] | ELBOW | KOBPF1/2 |
| 12. | LE03H01234P1 | [1] | CLAMP | KOB |
| 13. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 14. | YN03H01654P1 | [1] | TUBE | KOB |
| 15. | YN03H01653P1 | [1] | TUBE | KOB |
| 16. | YN20M01046DV | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 950.00mm | KOBProtective Plastic |
