| . . | NSS | [1] | NOT SOLD SEPARAT | CONCONTROL LINES - VALVE |
| . . | YM64H00014F1 | [1] | CONTROL LINES, VALVE (STD) | |
| . . | YM64H00014F2 | [1] | CONTROL LINES, VALVE (EXTRA) | |
| 1. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 2. | ZH22X06000 | [1] | HYD CONNECTOR | KOBPF3/8(Incls. O-Ring ZD12P01400) (FOR F1 Only) |
| 3. | 2420R349D145 | [2] | HOSE | KOBPF1/4, 1450mm Long (57-5/64 in) Superseded by part number: HX21E04145DX |
| 4. | 2420R349D210 | [1] | FLEXIBLE HOSE | KOBPF1/4, 2100mm Long (82-11/16 in) |
| 5. | 2420R349D165 | [1] | HOSE,1650.00 mm | KOBPF 1/4" Superseded by part number: HX21E04165DX |
| 6. | YN35V00039F1 | [1] | SOLENOID VALVE | KOBSEE CPM |
| 7. | 2444R1119D190 | [1] | HOSE | KOBPF3/8 L=1900mm |
| 8. | 2420R537D190 | [1] | FLEXIBLE HOSE,9.60mm ID x 1900mm L | KOBPF3/8 1900mm Long (74-13/16 in) Superseded by part number: HX21E06190DX |
| 9. | 2420R537D220 | [1] | HOSE,9.60mm ID x 2200mm L | KOBPF3/8 L=2200mm Superseded by part number: 77254115, HX21E06220DX |
| 10. | 2420R349D170 | [1] | FLEXIBLE HOSE | KOB(PF 1/4, 1700mm Long (66-59/64 in)) Superseded by part number: HX21E04170DX |
| 11. | 2420R349D155 | [1] | HOSE,6.35mm ID x 1150mm L | KOBPF 1/4 |
| 12. | 2420R349D130 | [1] | FLEXIBLE HOSE | KOB1/4" PF, 1300mm Long (51-3/16 in) |
| 13. | YN64H01175P1 | [2] | BUSHING | KOBID 13 x OD 21 x 40mm Long |
| 14. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004), (PF 1/4) |
| 15. | PY01P01043D6 | [6] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 16. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 17. | ZC46X22011 | [2] | CLIP | KOBClamp, Single Line -- ID 22 x 43mm Long |
| 18. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 19. | ZS18C10075 | [2] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| 20. | HH25X06006GA | [1] | HYD CONNECTOR | KOB3/8"PFx3/8"PFx37.5mm Long (Incls. O-Ring ZD12P01400) |
| 21. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 22. | YN64H01018P1 | [1] | GROMMET | KOB |
| 23. | ZH32X04000 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 24. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006, (FOR F1 Only) |
| 25. | 2444Z2891 | [1] | HYD CONNECTOR | KOB(PF3/8) (Incls. O-Ring ZD12P01400) |
| 26. | LQ32H01073D1 | [1] | RUBBER | KOBL=300mm |
| 27. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 28. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400), (FOR F2 Only) |
| 29. | HH55Q06006G1 | [2] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400), (FOR F2 Only) |
| 30. | ZH22X04006 | [1] | HYD CONNECTOR | KOBPF1/4-PF3/8 (Incls. O-Ring 237-6006) (FOR F2 Only) |
| 31. | PU13E01002DB | [1] | TUBE | KOB750mm Long (29-1/2 in) |
| 32. | 2479R2348 | [1] | SWITCH,95 Degrees C, 203 Degrees F | KOBHydraulic Oil Temperature (PT 3/8) |
| 33. | 2444Z2536 | [1] | TEE | KOBPF3/8 |
