神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-031) - CONTROL LINES - VALVE, P/N YM64H00030F1, F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
653 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONCONTROL LINES - VALVE |
| . . | YM64H00030F1 | [1] | CONTROL LINES, VALVE (EXTRA) | |
| 1. | YN35V00010F2 | [1] | VALVE | KOBSEE CPM |
| 2. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 3. | 2420R349D035 | [1] | HOSE | KOBPF 1/4, 350mm Long (13-49/64 in) |
| 4. | 2444R1120D040 | [1] | HOSE | KOBPF 1/4, 400mm Long (15-3/4 in) |
| 5. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 6. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004), (PF 1/4) |
| 7. | ZH32X04000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 8. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 9. | YM64H01022P1 | [1] | BRACKET | KOBBRACKET, PF1/4-PF3/8 |
| 10. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 11. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 12. | ZW16H06000 | [2] | WASHER | KOBID 06 x OD 15 x Th 3.2mm |
| 13. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
