神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-034[02]) - CONTROL LINES, PROPEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
760 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM62H00003F1 | [1] | CONTROL LINES,PROPEL | |
| 1. | YX30V00004F1 | [1] | VALVE | KOBSEE CPM Superseded by part number: YX30V00004F2 |
| 2. | HH25X04004G2 | [1] | HYD CONNECTOR | KOBPF 1/4, (Incls. O-Ring ZD12P01100) |
| 3. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long, Not Shown |
| 4. | ZH22X06000 | [1] | HYD CONNECTOR | KOBPF3/8(Incls. O-Ring ZD12P01400) |
| 5. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 5-1. | ZD12P01400 | [4] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 6. | ZS28C10025 | [4] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm |
| 7. | ZW16K10000 | [4] | WASHER | KOBID 10.5 x OD 18 x Th 2.0mm |
| 8. | YX52S00010P1 | [2] | SENSOR | KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1 |
| 8-1. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 9. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOBPF1/4, 900mm Long (35-7/16 in) |
| 10. | 2444R1119D100 | [1] | HOSE | KOB3/8" PF, 1000mm Long (39-3/8 in) |
| 11. | 2420R537D280 | [2] | HOSE,9.60mm ID x 2800mm L | KOBPF 3/8 |
| 12. | 2420R537D325 | [2] | FLEXIBLE HOSE,9.60mm ID x 3250mm L | KOBPF3/8 L=3250mm |
| 13. | YN68H01035P1 | [3] | CLAMP | KOB |
| 14. | ZS18C08040 | [6] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 15. | ZW16X08000 | [6] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 16. | PY01P01043D6 | [3] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 17. | YN64H01018P1 | [1] | GROMMET | KOB |
