| . . | YM06H00006F1 | [1] | CONTROL LINES, PUMP | |
| 1. | 2420R537D070 | [1] | HOSE,9.60mm ID x 700mm L | KOBPF3/8, 700mm Long (27-1/2 in) |
| 2. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 3. | 2420R349D085 | [1] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 4. | ZX22M12070 | [1] | HOSE ASSY. | KOBPF3/4 L=700mm |
| 5. | ZH22X06000 | [2] | HYD CONNECTOR | KOBPF3/8 (Incls. O-Ring ZD12P01400) |
| 6. | ZH32X06000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 6-1. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 7. | ZH42X12000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOB45° -- 3/4" PF (Incls. O-Ring 237-6012) |
| 8. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 9. | HH25R04004G5 | [1] | HYD CONNECTOR | KOBPF1/4 w/FILTER(Incls. O-Ring ZD12P01100) |
| 10. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 11. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 12. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 13. | HH55Q06006G1 | [4] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| 14. | ZS18C06060 | [2] | SCREW,Hex, M6 x 60mm | KOBM06x1.0x60mm |
| 15. | ZW16H06000 | [2] | WASHER | KOBID 06 x OD 15 x Th 3.2mm |
| 16. | YN50V00016F1 | [1] | FILTER | KOB |
| 17. | ZH32X04006 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 18. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 19. | HH35X04004G3 | [2] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 20. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 21. | YN35V00040F1 | [1] | VALVE | KOBAssembly, Solenoid Valve (Independent Travel) |
| 22. | 2420R349D056 | [1] | FLEXIBLE HOSE | KOBPF1/4 L=560mm Superseded by part number: 2420R349D060 |
| 23. | 2444R1120D030 | [2] | HOSE | KOBPF 1/4, 300mm Long (11-13/16 in) |
| 24. | 2444R1119D050 | [1] | HOSE | KOBPF 3/8, 500mm Long (19-11/16 in) |
| 26. | 2420R349D058 | [1] | HOSE | KOBPF1/4, 580mm Long (22-53/64 in) Superseded by part number: 2420R349D060 |
| 27. | 2420R349D046 | [1] | FLEXIBLE HOSE | KOBPF1/4 L=460mm Superseded by part number: 2420R349D050 |
| 28. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 29. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
