神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-041 ) - PLATE GROUP, FLOOR (BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00087F3 | [1] | PLATE | KOBPLATE GROUP, FLOOR (BREAKER) |
| A3. | YN26M00055P1 | [1] | FLOOR MAT | KOB |
| A4. | ZM22C08016 | [4] | BOLT | KOBM08x1.25x16mm (Incls. Washer & Lockwasher) |
| A6. | YN03M01335P1 | [1] | SUPPORT | KOB |
| A7. | YN03M01440P1 | [1] | COVER | KOB |
| A8. | YN03M01479P1 | [2] | COVER | KOB |
| A9. | 2420R603D6 | [1] | GROMMET | KOB |
| A10. | ZM27C08025 | [5] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| A11. | ZM22C10030 | [2] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| B1. | LC03M00008P1 | [1] | PLATE | KOBPLATE, FLOOR |
| . . | YN03M00023F1 | [1] | SPARE PART | KOBPLATE INSTAL, FLOOR |
| C1. | YN03M01245P1 | [4] | ENGINE MOUNT | KOB |
| C2. | ZM12C10030 | [16] | BOLT | KOBM10x1.50x30mm (Incls. Lockwasher) |
| C3. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| C4. | ZW26X16000 | [4] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| C5. | ZN18C16013 | [4] | NUT | KOBM16x2.0mm |
