神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-042 ) - CAB INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
933 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02C00019F1 | [1] | CAB | KOBCAB INSTALLATION |
| A1. | ZS18C12065 | [8] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| A2. | ZW26X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| A3. | 2418T10357 | [8] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| A4. | YT54C00003F1 | [1] | TANK | KOB |
| A6. | YN03M01159P1 | [1] | GROMMET | KOB |
| A7. | YT02C01126D3 | [1] | TUBE | KOB850mm Long (33-29/64 in) Superseded by part number: YT02C01126D7 |
| A15. | 2420R372D17 | [1] | GROMMET | KOBID 25 x OD 35 x hole 30 Th 08mm |
| A16. | YT02C01282P1 | [1] | ELEC CONNECTOR | KOB30mm Long (1-13/16 in) |
| A17. | 2427Z1594D078 | [1] | TRIM PANEL | KOB |
| A19. | ZM61C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| A20. | YN02C02983P1 | [1] | HANDRAIL | KOB |
| . . | YR02C01571D2 | [2] | SCREW | KOBFor Ref A20 Handrail, Not Shown |
| . . | ZW16H10000 | [2] | WASHER | KOBFor Ref A20 Handrail, Not Shown |
| B1. | YN02C00103F2 | [1] | CAB | KOB |
