约翰迪尔零件查询762B ATT - ATTACHMENTS ENGINE FEED WHEEL KIT F042683 11 92 TF1024 [TF1024]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
234 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
F045984
|
[1] |
WHEEL MOUNTING ASSY
|
|
| 1. |
F037274
|
[1] |
Plate
|
|
| 2. |
F037273
|
[1] |
DETECTOR CABLE
|
|
| 3. |
F037025
|
[2] |
Hydraulic Motor
|
|
| 4. |
F041376
|
[4] |
NIPPLE
|
|
| 5. |
F026256
|
[1] |
NIPPLE
|
|
| 6. |
F005089
|
[1] |
ELBOW NIPPLE
|
|
| 7. |
F041370
|
[1] |
HOSE-ASSY
|
|
| 8. |
F041371
|
[1] |
HOSE-ASSY
|
|
| 9. |
F041372
|
[1] |
HOSE-ASSY
|
|
| 10. |
F041373
|
[1] |
HOSE-ASSY
|
|
| 11. |
F041181
|
[1] |
PROTECTION PLATE
|
|
| 12. |
F041182
|
[1] |
PROTECTION PLATE
|
|
| 13. |
F003540
|
[8] |
Screw
|
|
| 14. |
F015376
|
[8] |
Washer
|
|
| 15. |
F026120
|
[2] |
Screw
|
|
| 16. |
F048251
|
[2] |
HOSE-ASSY
|
|
| 17. |
F005012
|
[4] |
Lock Washer
|
|
| 18. |
F003503
|
[4] |
Screw
|
|
| 19. |
F039611
|
[4] |
Washer
|
|
