神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-051) - BONNET ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
731 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM22C00006F1 | [1] | COVER | KOBBONNET ASSY |
| 1. | YM22C01015P2 | [1] | COVER | KOB |
| 1-7. | LC22C01028P1 | [2] | HINGE | KOB |
| 1-9. | ZS11C12030 | [4] | CAP,Hex, M12 x 30mm, Cl 4.8 | KOBScrew -- M12x1.75x30mm Superseded by part number: ZM12C12030 |
| 2. | YM22C01016P1 | [1] | FOAM INSULATION | KOB Superseded by part number: YM22C01028P1 |
| 3. | YN22C01099D1 | [1] | WEATHERSTRIP | KOBL-4980 |
| 4. | 2416T13435 | [2] | RUBBER | KOB |
