| . . | YN17M00033F1 | [1] | PANEL ASSY. | KOBPANEL ASSY, INSTRUM (STD) |
| . . | YN17M00033F2 | [1] | PANEL ASSY. | KOBPANEL ASSY, INSTRUM (NIBBLER&BREAKER) |
| 1. | YN17M01144P1 | [1] | COVER | KOBRH FORNT COVER |
| 2. | YN17M01145F1 | [1] | COVER | KOBRHSIDE COVER ASSY Superseded by part number: YN17M01130F2 |
| 2-4. | YN02C02055P1 | [1] | TRAY | KOBAsh |
| 2-5. | YN52S00032P1 | [1] | POTENTIOMETER | KOB(Used for Engine Acceleration) - High/Low Superseded by part number: YN52S00032P2 |
| . . | YN52S00032S001 | [1] | POTENTIOMETER | KOBNot Shown Superseded by part number: YN52S00032P2 |
| . . | YN52S00032S002 | [1] | KNOB | KOBNot Shown Superseded by part number: YN52S00032S003 |
| 2-6. | ZS31C04012 | [2] | BOLT,Phillips Drive, Pan HD, M4 x 12mm | KOB |
| 2-7. | ZW16K04000 | [2] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 2-8. | YN17M01128P1 | [1] | BRACKET | KOB |
| 2-9. | YN02C01877D2 | [4] | SCREW | KOBM03x10mm Self-Taper |
| 2-11. | YN17M01161F1 | [1] | COVER ASSY | |
| 2-11-1. | YN17M01146P1 | [1] | COVER | KOBRH COVER |
| 2-11-2. | YN17M01115P1 | [1] | COVER | KOBSWITCH PANEL |
| 2-11-3. | YN17M01116P1 | [1] | COVER | KOBPOKET |
| 2-11-4. | YN17M01069P1 | [1] | LABEL | KOBENGINE ACCEL |
| 2-11-5. | YN02C01877D2 | [5] | SCREW | KOBM03x10mm Self-Taper |
| 2-11-6. | YN02C01877D3 | [1] | SCREW,TAPPING | |
| 3. | YN59E00012F1 | [1] | GAUGE ASSY. | KOBSee figure 01-071 for breakdown of guage |
| 3-1. | YN59S00014F1 | [1] | GAUGE | KOBSee figure 01-071 for breakdown of guage |
| 3-2. | YN17M01140P2 | [1] | BRACKET | KOB |
| 3-3. | ZM41C05012 | [4] | BOLT | KOBM05x0.8x12mm (Incls. Washer & Lockwasher) |
| 4. | YN17M01147P1 | [1] | COVER | KOBFACE DUCT COVER |
| 3-4. | YN59S00012S005 | [3] | LAMP | KOBNot Shown |
| 5. | YN02C01877D2 | [4] | SCREW | KOBM03x10mm Self-Taper |
| 3-5. | YN59S00012S006 | [1] | LAMP | KOBNot Shown Superseded by part number: YN59S00012S005 |
| 6. | YN17M01148P1 | [1] | COVER | KOBCUP HOLDER |
| 7. | YN54S00006P1 | [2] | SPEAKER | KOB Superseded by part number: YN54S00050P2 |
| 8. | YN20M01380P1 | [1] | DUCT | KOBFACE&DEF DUCT |
| 9. | LB54S00001P1 | [1] | RADIO | KOBAM/FM Superseded by part number: YN54S00074P1 |
| 10. | ZS32T40012 | [8] | SCREW | KOBM04x12mm Self-Taper |
| 11. | YN81S00002P1 | [1] | CIGARETTE LIGHTER | KOB |
| 12. | ZM46C06020 | [18] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 13. | YN17M01149P1 | [1] | COVER | KOBLH CTRL BOX UPP COVER |
| 14. | YN17M01152F1 | [1] | COVER ASSY | KOBRH CTRL BOX UPP COVER |
| 14-1. | YN17M01135F1 | [1] | COVER | KOB |
| 14-1-1. | YN17M01123P1 | [1] | COVER | KOB |
| 14-1-2. | YN50S00026F1 | [1] | IGNITION SWITCH | KOBAssembly, Key -- (Incls. Keys YN50S01010P1) |
| 14-1-2-1. | YN50S01010P1 | [1] | SET OF 2 KEYS,Kobelco Branded | KOB(Part of YN50S00026F1) |
| 14-2. | YN17M01070P1 | [1] | LABEL | KOB |
| 15. | YN17M01150P1 | [1] | COVER | KOBCLUSTER LWRRH |
| 16. | YN17M01151P1 | [1] | COVER | KOBCLUSTER LWRLH |
| 17. | LC02C01004D2 | [2] | SCREW | KOB |
| 18. | YN20M01356P1 | [2] | DIFFUSER | KOB |
| 20. | YN58S00006P1 | [1] | METER | KOB |
| 21. | ZM61C08020 | [3] | BOLT | KOBM08x1.25x12mm (Incls. Washer & Lockwasher) |
| 23. | YN17M01072P1 | [1] | CABLE | KOB2000mm Long (78-3/4 in), FOR RADIO Superseded by part number: 72203961 |
| 24. | YN17M01132P1 | [5] | CAP | KOBCABEL |
| 25. | YN17M01055D2 | [1] | CAP | KOBLIGHT GRAY |
| 26. | YN17M01055D4 | [4] | CAP | KOBDRAK GRAY |
| 27. | ZW16P04000 | [8] | WASHER | KOBID 04 x OD 09 x Th 0.8mm, FOR SPEAKER INSTALLATION |
| 28. | ZS11C08016 | [1] | CAPSCREW,Hex, M8 x 16mm, Cl 4.8 | KOB Superseded by part number: ZS18C08016 |
| 29. | ZW11X08000 | [1] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 30. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOB |
| 31. | YN17M01142P1 | [2] | BRACKET | KOBFOR RADIO |
| 32. | 2479U1190F13 | [1] | SWITCH | KOBHEAVY LIFT |
| 33. | 2479U1190F5 | [1] | SWITCH | KOBTRAVEL INDEPENDENCE |
| 34. | 2479U1190F31 | [1] | SWITCH | KOBAutomatic Warm-Up |
| 35. | 2479U1190F32 | [1] | SWITCH | KOBDOUBLE FLOW FOR F2 ONLY |
| 36. | YN17M01032P1 | [6] | CAP | KOB |
| 37. | 2420R1089D1 | [4] | BOLT,M5 x 10mm | KOB(Incls. Washer & Lockwasher) |
| 38. | YN17M01143P1 | [1] | PLATE | KOB |
| 39. | YN17M01153D2 | [1] | COVER | KOB |
| 40. | YN17M01154P1 | [1] | SCREW | KOB |
