神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-056) - AIR CONDITIONER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
125 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM20M00010F1 | [1] | AIR CONDITIONER | |
| 1. | R18T0026D39 | [2] | HOSE | KOBID 12 x OD 22 x 4000mm |
| 2. | YM20M01013P1 | [1] | SUPPORT | KOBSUPPORT |
| 3. | YN20M01282D1 | [1] | V-BELT,48.82" L | KOB Superseded by part number: 84214731 |
| 4. | 2444T2577 | [2] | HYD CONNECTOR | KOBM16x1.5x51mm Long Ø14 Hose |
| 5. | ZC16X02000 | [4] | CLIP | KOBClamp, Hose -- Min 15 x Max 25mm |
| 6. | ZC48X24014 | [6] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| 7. | ZS18C10020 | [4] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 8. | 2432R233D1 | [1] | CLIP | KOB37x12x40mm |
| 9. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOBM06x1.0x20mm |
| 10. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 11. | ZS18C06050 | [6] | SCREW,Hex, M6 x 50mm | KOBM06x1.0x50mm |
| 12. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBScrew -- M08x1.25x100mm |
| 13. | ZW26X06000 | [6] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 14. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 15. | ZW16X10000 | [9] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 16. | ZW16X08000 | [6] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 17. | ZW16X06000 | [8] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 18. | HX81X22200DX | [2] | TUBE | KOBTUBE(L=2000MM) |
| 19. | HX81X25200DX | [1] | TUBE | KOBTUBE(L=2000MM) |
| 20. | HX81X19190DX | [1] | TUBE | KOBTUBE(L=1900MM) |
| 21. | YM20M01033P2 | [1] | SUPPORT | KOBSUPPORT |
| 23. | 2432R226D13 | [3] | CLIP | KOBClamp, Double -- ID 28 x 82mm Long |
| 24. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 26. | HX81X19210DX | [1] | TUBE | KOBTUBE(L=2100MM) |
| 27. | ZW26X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 28. | ZS18C10025 | [7] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 29. | ZS18C10035 | [1] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 30. | 2418T22259 | [1] | BOSS | KOB |
| 31. | YM20M01001P1 | [1] | BRACKET | KOB |
| 32. | HX81X22045DX | [1] | TUBE(L=450MM) | |
