神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-057[01]) - AIR CONDITIONER INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
749 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20M00076F1 | [1] | CONDITIONING UNIT | KOBAIR CONDITIONER INSTAL |
| 1. | YN20M01195P1 | [1] | GROMMET | KOB |
| 2. | ZM22C08025 | [7] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| 3. | YN02C01877D1 | [4] | SCREW | KOBM03x16mm Self-Taper |
| 4. | YN20M01428F1 | [1] | COVER ASSY | KOB |
| 4-1. | YN20M01429F1 | [1] | COVER ASSY | KOB |
| 4-1-1. | YN20M01430P1 | [1] | COVER | KOB |
| 4-1-3. | YN20M01418P1 | [1] | HOLDER | KOBHOLDER |
| 4-1-4. | ZM46C04020 | [4] | BOLT | KOBM04x0.7x20mm (Incls. Washer & Lockwasher) |
| 4-1-5. | ZN18C04003 | [4] | NUT | KOBM04x0.7mm |
| 4-1-6. | YN20M01130P1 | [2] | LOCK | KOB |
| 4-2. | YN20M01055P1 | [2] | GRILLE | KOB |
| 4-3. | YN17M01033D1 | [4] | SCREW | KOBM05x25mm |
| 4-4. | ZW16P05000 | [4] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 4-5. | ZW26X05000 | [4] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 4-6. | ZN18C05004 | [4] | NUT | KOBM05x0.8mm |
| 5. | YN20M01404F1 | [1] | COVER | KOB |
| 5-1. | YN20M01403P1 | [1] | COVER | KOB |
| 5-2. | YN20M01402P1 | [1] | COVER | KOB |
| 5-3. | YN20M01130P1 | [4] | LOCK | KOB |
| 5-4. | YN20M01285S004 | [4] | SCREW | KOB |
| 7. | ZS32T45010 | [3] | SCREW | KOBM4.5x10mm Self-Taper |
| 8. | ZM22C08020 | [11] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 9. | ZM66C06012 | [4] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| 10. | 2420R584 | [2] | FASTENER | KOB |
| 11. | YN17M01129P1 | [2] | BRACKET | KOB |
| 12. | YN02C01876D1 | [3] | SCREW | KOBM05x12mm Self-Taper |
| 13. | ZM66C06016 | [1] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 14. | YN20M01270P1 | [1] | DUCT | KOB |
| 15. | YN20M01431F1 | [1] | DUCT | KOB |
| 15-1. | YN20M01431S001 | [1] | DUCT | KOBDUCT |
| 15-2. | YN20M01431S002 | [1] | SEAL | |
| 15-3. | YN20M01431S003 | [1] | INSULATION | |
| 16. | YN20M01334F1 | [1] | DUCT | KOB |
| 17. | YN20M01258P1 | [1] | DUCT | KOB |
| 18. | YN20M01381P1 | [1] | DUCT | KOB |
| 19. | YN20M01382P1 | [1] | DUCT | KOB |
| 20. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 21. | YN20M01248P1 | [1] | SUPPORT | KOB |
| 22. | YN20M01274P1 | [1] | SUPPORT | KOB |
| 23. | YN20M01275P1 | [1] | SUPPORT | KOB |
| 24. | YN20M01271P1 | [1] | RUBBER | KOB |
| 25. | 2418T12346 | [1] | WASHER | KOBID 11 x OD 30 x Th 3.2mm |
| 26. | YN81S01001P1 | [1] | SOCKET | KOB |
| . . | YN20MU0001F1 | [1] | CONDITIONING UNIT | KOBINSTAL REWORK |
| A-1. | YN26CU1001P1 | [1] | FOAM INSULATION | KOBINSULATION |
