神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-059) - CONDTIONER ASSY, AIR, P/N YN20M00065F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
847 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20M00065F1 | [1] | CONDITIONING UNIT | KOB Superseded by part number: LC20M00005F2, 24100U1176S5, YT20M00009S005, YN52S00021F1, YN20M00016S078, LC20M01014D2, YT20M00009S006, YT20M01077P1 |
| 1. | LC20M00005F2 | [1] | AIR CONDITIONER,Assembly | KOB |
| 2. | YT20M01077P1 | [1] | PLATE | KOB |
| 3. | YT20M00009S005 | [1] | BOLT | KOB |
| 4. | LC20M01014D1 | [2] | HOSE | KOBID 11 x OD 15 x 300mm Superseded by part number: LC20M01014D2 |
| 6. | YN52S00021F1 | [1] | SENSOR | KOB |
| 8. | YN20M00016S078 | [2] | CLIP | KOB |
| 9. | YT20M00009S006 | [1] | CAP | KOB |
| 10. | 24100U1176S5 | [2] | CLAMP | KOB |
