凯斯零件查询(FLX4010) - FLOATER (8/04-8/06) (04-003[01]) - AXLE FRONT STEER, KNUCKLE PIN AND TIE ROD ASSY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
571 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87267421
|
[1] |
REPAIR KIT
|
BN
King Pin
|
| 2. |
87267422
|
[2] |
BOLT
|
BN
Stop
|
| 3. |
87267423
|
[2] |
JAM NUT
|
BN
Jam
|
| 4. |
87267424
|
[4] |
KEY
|
BN
Woodruff
|
| 5. |
87267419
|
[1] |
KNUCKLE
|
BN
ASSY. LH Superseded by part number: 84353650
|
| 6. |
87267420
|
[1] |
KNUCKLE
|
BN
ASSY. RH Superseded by part number: 84353653
|
| 7. |
87267418
|
[1] |
THREADED TIE-ROD
|
BN
End, RH
|
| 8. |
87267417
|
[1] |
THREADED TIE-ROD
|
BN
End, LH
|
| 9. |
NS
|
[1] |
NOT SERVICED
|
BAS
Tube
|
| 10. |
84180064
|
[1] |
TIE-ROD
|
BN
Assembly, Complete
|
| 13. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
Drum
|
| 14. |
87267430
|
[2] |
HUB CAP
|
BN
|
| 15. |
87267431
|
[2] |
GASKET
|
BN
Hub Cap
|
| 16. |
87267432
|
[2] |
ROLLER BEARING
|
BN
Outer
|
| 17. |
87267433
|
[2] |
BEARING CUP
|
BN
outer
|
| 18. |
87267434
|
[2] |
BEARING CUP
|
BN
inner
|
| 19. |
87267435
|
[2] |
ROLLER BEARING
|
BN
Inner
|
| 20. |
87267436
|
[2] |
SEAL
|
BN
Wheel Hub
|
| 21. |
84178258
|
[10] |
STUD
|
BN
Wheel, LH
|
| 22. |
84178256
|
[10] |
STUD
|
BN
Wheel, RH
|
| 23. |
84181750
|
[2] |
REPAIR KIT
|
BN
Brake, Major
|
| 24. |
84181455
|
[4] |
ROLLER
|
BN
Brake Shoe
|
| 25. |
84181457
|
[2] |
SPRING
|
BN
Shoe Return
|
| 26. |
84181458
|
[4] |
PIN
|
BN
Anchor, Brake Shoe
|
| 27. |
84181460
|
[2] |
SPRING
|
BN
Retaining, Brake Shoe
|
| 28. |
84181056
|
[1] |
CAMSHAFT
|
BN
LH - Brake
|
| 29. |
84181058
|
[1] |
CAMSHAFT
|
BN
RH - Brake
|
| 30. |
84175112
|
[4] |
BUSHING
|
BN
Camshaft
|
| 31. |
84181008
|
[1] |
BRACKET
|
BN
LH Brake Chamber
|
| 32. |
84181009
|
[1] |
BRACKET
|
BN
RH Brake Chamber
|
| 33. |
84181055
|
[2] |
CHAMBER
|
BN
Brake - Cam
|
| 35. |
84180992
|
[4] |
SEAL
|
BN
Brake Spider Superseded by part number: 84175120
|
| 36. |
84181334
|
[2] |
WASHER
|
BN
Inner Slack Adjustment
|
| 37. |
84181052
|
[2] |
ADJUSTER
|
BN
Slack - Auto
|
| 38. |
84185320
|
[1] |
INSTRUCTION
|
BN
Installation, Auto Slack Adjuster
|
| 39. |
84181337
|
[4] |
WASHER
|
BN
Shim
|
| 40. |
84181338
|
[4] |
WASHER
|
BN
Shim
|
| 41. |
84181341
|
[2] |
SNAP RING
|
BN
Camshaft Snap Ring Superseded by part number: 87267993
|
| 42. |
84181461
|
[4] |
RETAINER
|
BN
Roller, Brake Shoe
|
| 43. |
84180993
|
[4] |
BUSHING
|
BN
Anchor Pin
|
| 44. |
84181462
|
[4] |
PIN
|
BN
Spring
|
| 45. |
84175272
|
[2] |
WASHER
|
BN
Camhead Brake
|
| 46. |
84175121
|
[2] |
O-RING
|
BN
Camshaft
|
| 48. |
87389217
|
[1] |
SPIDER
|
BN
RH Brake Assembly
|
| 49. |
87389867
|
[1] |
SPIDER
|
BN
LH Brake Assembly
|
| 50. |
84173852
|
[1] |
FRONT AXLE
|
BN
Steer Superseded by part number: 87549254
|
| 52. |
84178193
|
[1] |
HUB
|
BN
Drum Assy, LH
|
| 53. |
84178192
|
[1] |
HUB
|
BN
Drum Assy, RH
|
| 54. |
87713233
|
[2] |
ARM
|
BN
Tie Rod - RH -F, R
|
| 55. |
87713238
|
[2] |
ARM
|
BN
Tie Rod - LH -F, R
|
| 56. |
87713434
|
[2] |
BEARING LOCK NUT
|
BN
Wheel Brg. Fin. Outer
|
| 57. |
87713435
|
[2] |
LOCK WASHER
|
BN
1.78" x 3.25" x .05"
|
| 58. |
87713450
|
[2] |
LOCKING RING
|
BN
Wheel Bearing, 3" od x 1.52" x .25"
|
| 59. |
87713452
|
[2] |
BEARING LOCK NUT
|
BN
Wheel Bearing Fin. Inner
|
| 60. |
84183831
|
[1] |
SHIELD
|
BN
Dust - RH Front Brake Superseded by part number: 84175362
|
| 61. |
84183832
|
[1] |
SHIELD
|
BN
Dust - RH Rear Brake
|
| 62. |
84183834
|
[1] |
SHIELD
|
BN
Dust - LH Front Brake Superseded by part number: 84175361
|
| 63. |
84183835
|
[1] |
SHIELD
|
BN
Dust - LH Rear Brake
|
