凯斯零件查询(FLX4010) - FLOATER (8/04-8/06) (04-010) - HANDRAIL GROUP, FLEXAIR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
942 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87267447
|
[1] |
HANDRAIL
|
TYR
Flexair CS
|
| 2. |
87267446
|
[1] |
HANDRAIL
|
TYR
Flexair RS Superseded by part number: 47462409
|
| 3. |
87267174
|
[2] |
BUMPER
|
BN
Tubular Door Stop
|
| 4. |
86639325
|
[18] |
WASHER,10.8mm ID x 24.5mm OD x 3mm Thk
|
FAR
|
| 5. |
9706704
|
[18] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 6. |
344098A1
|
[2] |
COVER
|
BN
Cradle Access
|
| 7. |
344358A1
|
[2] |
MAT
|
BN
Cradle Cover
|
| 8. |
16043224
|
[4] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
|
| 9. |
86624184
|
[4] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
