凯斯零件查询(FLX4010) - FLOATER (8/04-8/06) (04-017) - WALKWAY GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
602 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
342878A1
|
[1] |
EXTENSION
|
BN
walkway, RS
|
| 2. |
342879A1
|
[1] |
WALKWAY
|
TYR
CATWALK walkway, CS
|
| 3. |
342884A1
|
[1] |
PLATE
|
BN
FR splash CS
|
| 4. |
342883A1
|
[1] |
PLATE
|
BN
FR splash RS
|
| 5. |
342949A1
|
[1] |
PLATE
|
BN
RR splash CS
|
| 6. |
342948A1
|
[1] |
PLATE
|
BN
RR splash RS
|
| 7. |
343807A1
|
[2] |
SUPPORT
|
BN
Brace, Rear Splash Plate
|
| 8. |
344095A1
|
[1] |
COVER
|
BN
hydraulic filter access
|
| 9. |
344360A1
|
[1] |
MAT
|
BN
Walkway RS
|
| 10. |
344359A1
|
[1] |
MAT
|
BN
Oil Tank Cover
|
| 11. |
86624184
|
[34] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 12. |
120104
|
[23] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
344361A1
|
[1] |
MAT
|
BN
Walkway CS
|
| 14. |
86986696
|
[1] |
GUARD
|
BN
Exhaust Pipe
|
| 15. |
342960A1
|
[1] |
PANEL
|
BN
Rear Filler, RS
|
| 16. |
342951A1
|
[1] |
PANEL
|
BN
Rear Filler, CS
|
| 17. |
343812A1
|
[1] |
PANEL
|
BN
Front Filler, CS
|
| 18. |
342950A1
|
[1] |
PANEL
|
BN
Front Filler, CS
|
| 19. |
343811A1
|
[1] |
PANEL
|
BN
Front Filler, RS
|
| 20. |
342959A1
|
[1] |
PANEL
|
BN
Front Filler, RS
|
| 21. |
86639325
|
[44] |
WASHER,10.8mm ID x 24.5mm OD x 3mm Thk
|
FAR
|
| 22. |
11106231
|
[28] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
| 23. |
86528579
|
[11] |
NUT,M8 x 1.25
|
WIN
|
| 24. |
100037
|
[12] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
BN2394894
|
[8] |
RIVET
|
BN
Pop 97525A032 3/16X
|
| 26. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
