凯斯零件查询(FLX4010) - FLOATER (8/04-8/06) (04-016) - FENDER GROUP, FRONT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
427 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86986680
|
[1] |
FENDER
|
TYR
Front, CS
|
| 2. |
86986681
|
[1] |
FENDER
|
BN
Front, RS
|
| 3. |
86986682
|
[2] |
MOUNTING PLATE
|
BN
Park/Turn LT
|
| 4. |
86588450
|
[16] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 5. |
120100
|
[8] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 6. |
353308
|
[8] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 7. |
86639325
|
[60] |
WASHER,10.8mm ID x 24.5mm OD x 3mm Thk
|
FAR
|
| 8. |
43140
|
[30] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 9. |
100037
|
[30] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
87267088
|
[1] |
RETAINER
|
BN
Assembly, Deutsch RH Superseded by part number: 87716495, 87267086, 87029192B
|
| 11. |
BN52348
|
[2] |
BOLT,Phil Pan Hd, #10 - 32 x 1/2", Stainless
|
CUR
10-32 X 1/2 SSPH, Phillip
|
| 12. |
225-14210
|
[2] |
NUT,#10-32
|
CAS
Superseded by part number: 87825, 72187047
|
| 13. |
87267087
|
[1] |
RETAINER
|
BN
Assembly, Deutsch LH Superseded by part number: 87029192B, 87716495, 87267086
|
