神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (05.100.10[01]) - ISL LIST A Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
169 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20M01414D2 | [1] | BELT, TRANSMISSION | KOBAir Conditioner |
| 2. | 2853208 | [1] | BELT,1660.00 mm L, 8 Ribs | CASWater Pump Superseded by part number: 504079075 |
| 3. | 84228510 | [1] | ENGINE OIL FILTER | NH Superseded by part number: 84228488 |
| 4. | 2852684 | [1] | BREATHER | TOREngine Breather Filter Superseded by part number: 504069559 |
| 5. | YN52V01016F3 | [1] | FILTER ASSY | KOB |
| 6. | 84348882 | [1] | FUEL FILTER,97mm OD x 184mm L, M16 x 1.5, 30 Microns | CAS |
| 7. | YM11P01033P1 | [1] | AIR FILTER | KOBPrimary Superseded by part number: 87682990 |
| 8. | YM11P01032P1 | [1] | AIR FILTER | KOBSecondary Superseded by part number: 87683000 |
| 9. | LQ50V01008P1 | [1] | CAB FILTER | SMA/C (Outer) Superseded by part number: 47814794 |
| 10. | YW50V00004F7 | [1] | FILTER STRAINER | KOB |
