| 1. | YM01V00019R300 | [1] | REPAIR KIT | KOBBoom Cylinder |
| 2. | YM01V00017R300 | [1] | REPAIR KIT | KOBArm Cylinder |
| 3. | YM01V00018R300 | [1] | REPAIR KIT | KOBBucket Cylinder |
| 4. | 2856350 | [1] | SENSOR | TOR(Used for Injection Pump - Water Temp) Superseded by part number: |
| 5. | YN50S00048P1 | [1] | THERMOSTATIC SWITCH,On, 10 Degrees C, 50 Degrees F; Off, -12 Degrees C, 10.4 Degrees F | KOB(87568522) (Used for Engine Temp Sensor) Superseded by part number: 87568522 |
| 6. | 2853427 | [1] | PROBE | TOR(Used for Engine Oil Level) Superseded by part number: 504025612 |
| 7. | 84322388 | [1] | THERMOSTAT | TORAssembly Superseded by part number: 504380075 |
| 8. | 2853432 | [1] | DIPSTICK | TORAssembly Superseded by part number: 504045917 |
| 9. | 84377568 | [1] | STARTER MOTOR,24V, 4kW | KOB Superseded by part number: 5801577136 |
| 9. | 84377568R | [1] | REMAN-STARTER,24V, 4kW | MKT |
| 9. | 84377568C | [1] | CORE-STARTER,24V, 4kW | MKTReturn Number |
| 10. | YN52S00045F1 | [1] | SENSOR | SM(Used for Fuel Level) |
| 11. | 87748274 | [1] | PLUG | SMFuel Tank Cap |
| 12. | YN57V00004F1 | [1] | BREATHER | KOB Superseded by part number: YN57V00010F1 |
| 13. | YN05P00010S006 | [1] | RADIATOR CAP | KOBRadiator Superseded by part number: YN05P00088S032 |
| 14. | LQ51D01007P1 | [1] | SPROCKET,21 T with 30 Holes, 402mm ID x 659mm OD | KOB |
| 15. | 87606376 | [1] | RADIATOR HOSE,44.00 mm ID, 49.00 mm ID x 451.00 mm | SM |
| 16. | 87606365 | [1] | RADIATOR HOSE,44.00 mm ID, 49.00 mm ID x 360.00 mm | SM |
| 17. | LQ53C01001S003 | [1] | WIPER BLADE | KOB |
| 18. | YN50S01010P1 | [1] | SET OF 2 KEYS,Kobelco Branded | KOBIgnition Key |
| 19. | YN24S00004P1 | [1] | RELAY,24V, 150 Amp | KOB(71451677) (Used for Intake Grid Heater) |
| 20. | YN24S00009P1 | [1] | RELAY,24V, 50 Amp | KOB(71403889) (Used for Starter & Fuel Filter) |
| 21. | 338060A1 | [1] | FUSE,60A, Mini, Blue | CASLight Blue (YN73E00026P1) |
| 22. | 8501311 | [1] | FUSE,150A, Megaval | FAR |
| 23. | 82033971 | [1] | FUSE,100A, Maxi, Violet | BAS(YN73E00027P1) |
| 24. | YN24E00016S005 | [1] | FUSE,5amp | SM |
| 25. | YN24E00016S006 | [1] | FUSE,10amp | SM |
| 26. | YN24E00016S007 | [1] | FUSE,15amp | SM |
| 27. | YN24E00016S008 | [1] | FUSE,20amp | SM |
| 28. | YN50S00040D2 | [1] | SWITCH | KOB(84164716) (Used for Rotary or Beacon Light) |
| 29. | YN50S00040D1 | [1] | LIGHT SWITCH | SM(Used for Boom/Deck Work Light) |
| 30. | YN50S00040DB | [1] | SWITCH | KOB(Used for Independent Travel) |
| 31. | YN50S00040D5 | [1] | SWITCH | KOB(87540814) (Used for Heavy Lift) |
| 32. | YN24S00010P1 | [1] | RELAY | KOB(87559156) (Used for Horn, Glow, Work Light, Travel Alarm, Cab Work Light, Revolution LH/RH, Auto Idle Stop 1, Neutral Stop, Window washer Motor, Prevent Spark, Wiper Motor Reversing, Restart Prevention, Main, Air Conditioner Blower) |
| 33. | YN24S00008F1 | [1] | RELAY | KOB(87559395) (Used for Battery) |
| 34. | YN24S00012P2 | [1] | RELAY,24V | SM(87611990) (Used for Wiper Motor, Prevent Spark) |
