神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (10.202.AD) - AIR CLEANER INSTALL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
923 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87570248 | [1] | AIR FILTER | SM(YM11P00009F1) |
| 2. | 87345227 | [1] | FLEXIBLE HOSE | SM(YM11P01026P1) 541mm Long (21-19/64 in) |
| 3. | 87345229 | [1] | FLEXIBLE HOSE | SM(YM11P01027P1) 163mm Long (6-13/64 in) (90� Elbow) |
| 4. | 47482556 | [1] | FLEXIBLE HOSE,21mm ID x 1050mm L | SM |
| 5. | 71403661 | [1] | CLAMP,35mm ID, 12.5mm Bolt Hole, P Type | LEC(ZC46X31014) �31mm Single Cable Superseded by part number: 85802889 |
| 6. | 72220488 | [2] | HOSE CLAMP | SM(ZC16X11000) Min 100 x Max 121mm |
| 7. | 72220486 | [2] | HOSE CLAMP | SM(ZC16X08700) |
| 8. | 422050700 | [2] | CLAMP | IMO(ZC16X03300) Superseded by part number: 154220507 |
| 9. | 11106234 | [13] | BOLT,Hex, M10 x 1.5 x 25 mm, Cl 10.9, Full Thd | BUR(ZS18C10025) M10 x 1.50 x 25 Superseded by part number: 11106231 |
| 10. | 10516874 | [13] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | TTF(ZW26X10000) ID 10 x OD 18 x Th 2.5mm Superseded by part number: 140028 |
| 11. | 14496631 | [13] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC(ZW16X10000) ID 10 x OD 21 x Th 2.0mm Superseded by part number: 14496621 |
| 12. | YM11P01040P1 | [1] | PLATE | SM |
| 13. | 72210112 | [1] | RIGID TUBE,149.5 mm Length | SMAir Intake (YM11P01020P1) |
