神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (10.210.AF[01]) - FUEL LINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
662 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM21P01013F1 | [1] | FILTER ASSY | SMAssembly |
| 2. | 14496631 | [8] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC(ZW16X10000) Superseded by part number: 14496621 |
| 3. | 71403661 | [2] | CLAMP,35mm ID, 12.5mm Bolt Hole, P Type | LEC(EW02E01026D6) Superseded by part number: 85802889 |
| 4. | YM21P01016P1 | [1] | FLEXIBLE HOSE | KOB |
| 5. | 72960378 | [1] | HOSE,6mm ID x 400mm L | SM(HX11Y04040DX) Superseded by part number: 72280610 |
| 6. | 11106034 | [4] | BOLT,Hex, M10 x 20, 10.9, Full Thd | BUR(ZS18C10020) Superseded by part number: 11106031 |
| 7. | 72951499 | [10] | CLIP | IMO(PY01P01043D8) Superseded by part number: PY01P01043D8 |
| 8. | YN21P01125P1 | [1] | HOSE,10mm ID x 450mm L | KOB |
| 9. | YB21P01029P1 | [1] | FLEXIBLE HOSE,10mm ID x 2090mm L | SM |
| 10. | YM21P01002P1 | [1] | FUEL HOSE,6mm ID x 2800mm L | KOB |
