神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (10.216.AI) - FUEL TANK INSTALL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
442 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 11118534 | [4] | SCREW | HIT(ZS13C16040) Superseded by part number: 11118537 |
| 2. | 71405003 | [4] | WASHER | TOR(ZW13H16000) Superseded by part number: 98416514 |
| 3. | 72202973 | [3] | SHIM,1mm Thk | SM(LE33H01017D1) Superseded by part number: 84532273 |
| 4. | 87539072 | [1] | SENSOR | SM(YN52S00045F1) Superseded by part number: YN52S00045F1 |
| 5. | 4976587 | [1] | PLUG,1/4" | LEC(YB20P01063P1) |
| 6. | 13274024 | [5] | SCREW,Pozidriv Pan Hd, M5 x 12mm, Cl 8.8, Full Thd | IMO(ZS31C05012) Superseded by part number: 13274021 |
| 7. | 11195474 | [5] | WASHER | HIT(ZW26X05000) Superseded by part number: 11195471 |
| 8. | 71405229 | [1] | HYD CONNECTOR | LEC(YB20P01062P1) |
| 9. | 71405228 | [1] | DRAINCOCK/TAP SUPPLY | LEC(YB20P01061P1) |
