神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (10.220.AM) - ENGINE, CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
967 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 72204659 | [1] | SMALL ELECTRIC MOTOR | SM(YN20S00002F2) Governor Superseded by part number: YN20S00002F1 |
| 2. | 87568283 | [1] | LEVER | SM(YB11M01022P1) Superseded by part number: YB11M01022P1 |
| 3. | 87571531 | [1] | PLATE | SM(YB11M01030P1) |
| 4. | 72209399 | [1] | BALL JOINT | SM(YN11M01218D1) Superseded by part number: YN11M01218D1 |
| 5. | 16043634 | [6] | SCREW,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd | LEC(ZS18C08025) Superseded by part number: 16043637 |
| 6. | 87568288 | [1] | BRACKET | SM(YB11M01027P1) |
| 7. | 14420334 | [3] | HEX SOC SCREW,M10 x 1.5 x 35mm, Cl 10.9, Full Thd | LEC(ZS28C10035) Superseded by part number: 14420331 |
| 8. | 87568290 | [1] | ROD | SM(YB11M01029P1) |
| 9. | 12164721 | [1] | NUT,M10 x 1.25, Cl 10 | TTF(ZN18F10008) |
| 10. | 10789721 | [1] | NUT,M10 x 1.25, Cl 10, LH | LEC(YR12B01082P1) |
| 11. | 72209400 | [1] | BALL JOINT | SM(YN11M01218D2) Superseded by part number: YN11M01218D2 |
| 12. | 10516674 | [2] | LOCK WASHER,M8 | TTF(ZW26X08000) Superseded by part number: 83990583 |
| 13. | 16100821 | [2] | NUT,M8, Cl 10 | LEC(ZN18C08007) Superseded by part number: 17037925 |
| 15. | 10902434 | [3] | SCREW,Hex, M6 x 20mm, Cl 10.9, Full Thd | LEC(ZM73C06020) Superseded by part number: 86505530 |
| 16. | 12646701 | [6] | WASHER,8.15mm ID x 20mm OD x 2mm Thk | TTF(ZW16H08000) Superseded by part number: 12646721 |
| 17. | 14496431 | [3] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 18. | 11701721 | [3] | NUT,M10, Cl 10 | LEC(ZN18C10008) Superseded by part number: 17038131 |
| 19. | 14496631 | [3] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC(ZW16X10000) Superseded by part number: 14496621 |
| 20. | 87515291 | [1] | BRACKET | SM(YB11M01020P1) |
