神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (10.400.BF[02]) - RADIATOR INSTALL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
428 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87605148 | [1] | PLATE | SMAssembly YB05P01161F1, Incl 2 - 5 |
| 2. | 87605150 | [1] | FOAM INSULATION | KOB(YB05P01163P1) Superseded by part number: YB05P01163P1 |
| 3. | 87340492 | [1] | FOAM INSULATION | KOB(YB05P01040P1) Superseded by part number: YB05P01040P1 |
| 4. | 87340494 | [1] | SOFT TRIM | KOB(YB05P01041P1) Superseded by part number: YB05P01041P1 |
| 5. | 87605149 | [1] | PLATE | KOB(YB05P01162P1) Superseded by part number: YB05P01162P1 |
| 6. | 87340497 | [1] | PLATE | SMAssembly YB05P01043F1, Inc 7 - 8 |
| 7. | 87340499 | [1] | PLATE | KOBPLATE (YB05P01044P1) |
| 8. | 87340501 | [1] | INSULATION | KOBFOAM INSULATION (YB05P01045P1) Superseded by part number: YB05P01045P1 |
| 9. | 87340503 | [1] | PLATE | SMAssembly YB05P01046F1, Inc 10 - 11 |
| 10. | 87340504 | [1] | PLATE | KOBPLATE (YB05P01047P1) |
| 11. | 87340505 | [1] | INSULATION | KOBFOAM INSULATION (YB05P01048P1) Superseded by part number: YB05P01048P1 |
