神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.100.BH) - HYD. LINE, PUMP, CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
670 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZX22M12105 | [1] | HOSE,19.05mm ID x 1050mm L | KOB(CNH 72214753) |
| 2. | 2420R537D055 | [1] | HOSE ASSY.,9.60mm ID x 550mm L | KOB(CNH 72953739) |
| 3. | 2420R349D048 | [1] | HOSE ASSY. | KOB(CNH 87557643) Superseded by part number: 2420R349D050 |
| 4. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMInline, (CNH 87338500) |
| 5. | YM06H01004P1 | [1] | TEE | KOB(CNH 87576368) |
| 6. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB(CNH 72217409) w/filter (PF 1/4)(Incl O-Ring ZD12P01100) |
| 7. | ZH42X12000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOB(CNH 87338502) |
| 8. | ZH22X06000 | [1] | HYD CONNECTOR | KOB(CNH 72214523) |
| 9. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90?, (CNH 72214734) |
| 10. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB(CNH 72214526) Elbow, 90? -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 11. | ZH32X04000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOB90?, (CNH 72214524) |
| 12. | YM06H01003P1 | [1] | HYD CONNECTOR | KOB(CNH 87576367) |
| 13. | 2444Z3571 | [1] | HYD CONNECTOR | SM(CNH 87608111) |
| 14. | 2420R537D045 | [1] | HOSE,9.60mm ID x 450mm L | KOB(CNH 87573160) Superseded by part number: HX21E06045DX |
| 15. | ZH42X06000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB(CNH 72214541) |
