神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.106.AN[01]) - HYDRAULIC PUMP, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
730 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | 87586077 | [1] | PTO Assembly (YB30P00004F1) | |
| .. | YB30P00004F1 | [1] | PTO | KOBAssembly (87586077) |
| 1. | YB10V01001F3 | [2] | REGULATOR | KOB |
| 2. | YN35V00054F1 | [2] | SOLENOID VALVE | KOB |
| 3. | YX10V00004F3 | [1] | HYDRAULIC PUMP | SMGear |
| 4. | YB46W00001F2 | [1] | GEAR | KOBGear Pump Case |
| 5. | YB10V00006F2 | [1] | HYDRAULIC PUMP | SMHyd Pump Superseded by part number: YB10V00005F3 |
| 5. | YB10V00005F3 | [1] | HYDRAULIC PUMP | KOBAssembly |
