神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.352.AL) - MOTOR INSTALL, SWING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
617 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZS18C20055 | [13] | SCREW,Hex, M20 x 55mm | KOB(CNH 11124834) |
| 2. | YN64H01391D1 | [2] | CAP | KOB(CNH 87643225) |
| 3. | YN32W01101D1 | [1] | LEVEL GAUGE | SM(CNH 87369427) |
| 4. | YN32W01114D4 | [1] | RIGID TUBE | SM |
| 5. | YN32W01122D1 | [1] | RIGID TUBE | SM(CNH 84189984) |
| 6. | ZE91T12000 | [1] | PLUG | SMCap, (CNH 87369430) |
| 7. | YM15V00008F1 | [1] | HYDRAULIC MOTOR | SMSwing Hydraulic Motor Assembly |
| 7-1. | YM15V00006F1 | [1] | HYDRAULIC MOTOR | KOBAssembly (CNH 87571454) |
| 7-2. | YM32W00009F1 | [1] | GEAR REDUCTION UNIT | SMSwing Gear Reduction Unit |
