神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.352.AL[02]) - SWING REDUCTION UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
396 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM32W01003P1 | [1] | SHAFT | SM |
| 2. | YN32W01136P1 | [1] | GEAR | SM |
| 3. | YN32W01135P1 | [3] | GEAR | SM |
| 4. | YN32W01126P1 | [1] | GEAR | SM |
| 5. | YN32W01143P1 | [4] | GEAR | SM |
| 6. | YN32W01127P1 | [1] | GEAR | SM |
| 7. | YN32W01123F1 | [1] | SPIDER | KOB |
| 8. | YN32W01130P1 | [1] | PLANET CARRIER | SM |
| 9. | YN32W01131P1 | [4] | SHAFT | SM |
| 10. | YN32W01030P1 | [1] | SPHERICAL BEARING | KOB Superseded by part number: 25Z804D18 |
| 11. | YN32W01029P1 | [1] | SPHERICAL BEARING | KOB Superseded by part number: R25P0047D9 |
| 12. | YN32W01060P1 | [1] | OIL SEAL | SM |
| 13. | YN32W01132P1 | [1] | BOX | SM |
| 14. | YN32W01026P1 | [3] | THRUST WASHER | KOB |
| 15. | YN32W01028P1 | [3] | THRUST WASHER | KOB |
| 16. | YN32W01022P1 | [102] | ROLLER | KOB |
| 17. | YN32W01072P1 | [4] | NEEDLE BEARING | SM |
| 18. | YN32W01063P1 | [8] | WASHER | SM |
| 19. | 11068370 | [1] | SNAP RING | MKT Superseded by part number: 11068375 |
| 20. | ZR16X09000 | [1] | RING | KOB |
| 21. | YN32W01133P1 | [1] | SLEEVE | SM |
| 22. | 72210023 | [4] | PIN | SM Superseded by part number: ZP26D08025 |
| 23. | 72210021 | [11] | SCREW,Hex Socket Head, M14 x 130mm | SM Superseded by part number: ZS23C14130 |
| 25. | YN32W01080D5 | [1] | RIGID TUBE | SM |
| 26. | ZG31U08000 | [1] | HYD CONNECTOR | SM |
| 27. | 72210000 | [1] | PLUG | SM Superseded by part number: ZE82T08000 |
| 28. | 72211282 | [3] | SNAP RING | SM Superseded by part number: ZR16X04000 |
| 29. | YN32W01081P1 | [1] | OIL SEAL | SM |
| 30. | 72283072 | [1] | LUBE NIPPLE,67 Degree x 1/8" PT | IMO Superseded by part number: ZG91V02000 |
| 31. | 72210250 | [1] | PLUG | IMO Superseded by part number: ZE82T02000 |
| 100. | YM32W00009F1 | [1] | GEAR REDUCTION UNIT | SMAssy, Contains 1 to 3, Serial Range: 1-31 |
