神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.353.AE) - HYD. LINE, CONTROL (PROPEL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
296 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN30V00105F2 | [1] | PILOT VALVE | KOB |
| 2. | 2420R349D074 | [1] | HOSE,740.00 mm | SM Superseded by part number: 2444R3019D3 |
| 3. | 2420R349D078 | [1] | FLEXIBLE HOSE | SM Superseded by part number: 2420R349D080 |
| 4. | 2420R349D160 | [2] | HOSE,6.35mm ID x 1600mm L | KOB |
| 5. | HX33L06082DX | [2] | FLEXIBLE HOSE | SM |
| 6. | 2420R349D165 | [2] | HOSE,1650.00 mm | KOB Superseded by part number: HX21E04165DX |
| 7. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB |
| 8. | ZH22X04006 | [1] | HYD CONNECTOR | KOB |
| 9. | ZH32X04006 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| 10. | LC52S00019P1 | [2] | SENSOR | SM(Low Pressure) (Used for Bucket, Boom Up/Down, Swing LH/RH, Arm In/Out, Travel LH/RH, P1/P2 Option, Dozer, N&B Revolution, Boom Rod Press, Boom Overload Alarm, Auto Accel, Option Selector Detect) (Incls. O-Ring ZD12P01100) |
| 11. | YN62H01015P1 | [2] | RUBBER BAND | KOB |
| 12. | YF62H01001P1 | [2] | RUBBER BAND | KOB |
| 13. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOB |
| 14. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 15. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| 16. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
