神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.355.AK.[01]) - JOYSTICK, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
972 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LB03M01017F1 | [1] | HANDLE GRIP | SM(RH) Assembly, Incl 2 - 15 |
| 2. | YY03M01239F1 | [1] | HANDLE | KOB(RH) |
| 1. | YN03M02122F1 | [1] | HANDLE | SM(LH) Assembly, Incl 2 - 15 |
| 2. | YY03M01240F1 | [1] | HANDLE GRIP | KOB(LH) |
| 3. | ZS32T30016 | [4] | SELF-TAP SCREW | KOB |
| 4. | PW03M01958S404 | [1] | PLUG | KOB |
| 5. | PW03M01958S405 | [1] | BRACKET | KOB |
| 6. | PW03M01958S407 | [2] | RETAINER | KOB |
| 7. | PW03M01958S408 | [2] | PLUG | KOB |
| 8. | PW03M01958S411 | [2] | PISTON | KOB |
| 9. | PW03M01958S421 | [2] | SPRING | KOB |
| 10. | PW03M01958S451 | [1] | CAP | KOB |
| 11. | PW03M01958S471 | [1] | SCREW | KOB |
| 12. | PW03M01958S472 | [4] | SCREW | KOB |
| 13. | ZS32T30006 | [3] | SELF-TAP SCREW | KOB |
| 14. | ZS32T30008 | [1] | SELF-TAP SCREW | KOB |
| 15. | PW03M01958S482 | [1] | SWITCH | KOB |
| 16. | PW03M01959S482 | [1] | SWITCH | KOB |
| 17. | PW03M01958S852 | [1] | COVER | KOB |
| 18. | PW03M01958S853 | [2] | CAP | KOB |
| 19. | EN52S01001D6 | [1] | HYD CONNECTOR | KOB |
| 20. | EN52S01005D6 | [1] | HOLDER | KOB |
| 21. | PW03M01958S885 | [6] | TERMINAL CONNECTOR | KOB |
| 22. | PW03M01959S886 | [1] | HOUSING | KOB |
| 23. | PW03M01959S887 | [2] | TERMINAL CONNECTOR | KOB |
| 24. | PW03M01958S888 | [6] | SEAL | KOB |
| 25. | PW03M01958S889 | [1] | TERMINAL CONNECTOR | KOB |
| 26. | PW03M01958S891 | [1] | TUBE | KOB |
| 27. | PW03M01958S892 | [2] | CLIP | KOB |
