神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.355.AK.[02]) - JOYSTICK, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
821 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LB03M01013F1 | [1] | HANDLE GRIP | SMAssembly, Incl 2 - 17 |
| 1. | YN03M02123F1 | [1] | HANDLE GRIP | SMAssembly, Incl 2 - 17 |
| 2. | PW03M01960F1 | [1] | HANDLE | KOBAssembly, Incl 3 - 15 |
| 3. | ZS32T30016 | [1] | SELF-TAP SCREW | KOB |
| 4. | PW03M01958S408 | [1] | PLUG | KOB |
| 5. | PW03M01958S404 | [1] | PLUG | KOB |
| 6. | PW03M01960S405 | [1] | BRACKET | KOB |
| 7. | PW03M01958S409 | [1] | PLUG | KOB |
| 8. | PW03M01958S472 | [2] | SCREW | KOB |
| 9. | ZS32T30006 | [2] | SELF-TAP SCREW | KOB |
| 10. | PW03M01959S482 | [1] | SWITCH | KOB |
| 11. | PW03M01958S853 | [2] | CAP | KOB |
| 12. | PW03M01959S886 | [1] | HOUSING | KOB |
| 13. | PW03M01959S887 | [2] | TERMINAL CONNECTOR | KOB |
| 14. | PW03M01958S891 | [1] | TUBE | KOB |
| 15. | PW03M01958S892 | [2] | CLIP | KOB |
| 16. | 14601271 | [1] | ROLL PIN | LEC Superseded by part number: 14601270 |
| 17. | YN03M02124P1 | [1] | LEVER | SM |
