Pos.	Part No	Qty	Parts name	Comments
..	YM30V00013F1	[1]	CONTROL VALVE	KOB
163.	ZD12P01800	[2]	O-RING	KOBID 17.8mm x OD 20.2mm
273.	ZS23C08025	[40]	SCREW,Hex Socket Head, M8 x 25mm	KOBM08x1.25x25mm
606.	LB30V00015F1	[2]	VALVE PRESSURE RELIE	KOBASSY
977.	NSS	[1]	NOT SOLD SEPARAT	CONNAME PLATE
978.	NSS	[2]	NOT SOLD SEPARAT	CONPIN
K.	YM30V00008R100	[1]	KIT	SMREPAIR KIT CONSISTS OF ITEM, 301X1, 319X1, 320X1, 331X2, 333X1, 339X1
K.	YM30V00008R110	[1]	KIT	SMREPAIR KIT CONSISTS OF ITEM, 302X1, 321X1, 322X1, 331X2, 333X1, 336X1
K.	YM30V00008R120	[1]	KIT	SMCONSISTS OF ITEM 303X1, 321X1, 322X1, 331X2, 333X1, 336X1
K.	YM30V00008R210	[1]	KIT	SMREPAIR KIT CONSISTS OF ITEM, 304X1, 319X1, 320X1, 331X2, 333X1, 339X1
K.	YM30V00008R140	[1]	KIT	SMCONSISTS OF ITEM 305X1, 321X1, 322X1, 331X2, 333X1, 339X1
K.	YM30V00011R150	[1]	SPOOL	KOBCONSISTS OF ITEM 306X1, 325X1, 327X1, 331X2, 333X1, 339X1
K.	YM30V00011R160	[1]	KIT	KOBCONSISTS OF ITEM 307X1, 325X1, 328X1, 331X2, 333X1, 336X1
K.	YM30V00008R170	[1]	KIT	SMREPAIR KIT CONSISTS OF ITEM, 308X1, 325X1, 326X1, 331X2, 333X1, 339X1
K.	YY30V00058R210	[1]	SPOOL	KOBCONSISTS OF ITEM 309X1, 325X1, 328X1, 331X2, 333X1, 336X1
K.	YY30V00058R220	[1]	SPOOL	KOBCONSISTS OF ITEM 310X1, 325X1, 328X1, 331X2, 333X1, 336X1
K.	YM30V00008R200	[1]	KIT	SMCONSISTS OF ITEM 311X1, 329X1, 330X1, 331X2, 333X1, 337X1
