神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.359.AG[02]) - CONTROL VALVE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
150 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YM30V00013F1 | [1] | CONTROL VALVE | KOB |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 102. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 154. | YN30V00001S154 | [2] | PLUG | KOB |
| 155. | YW30V00001S155 | [2] | PLUG | KOB1/2" |
| 160. | NSS | [5] | NOT SOLD SEPARAT | CONPLUG |
| 162. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 163. | ZD12P01500 | [4] | O-RING | KOB |
| 164. | ZD12P02500 | [6] | O-RING | KOBID 24.7mm x OD 28.2mm |
| 169. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 207. | YN30V00101S207 | [1] | GUARD | SMCOVER Superseded by part number: YN30V00101S094 |
| 264. | ZD12G04000 | [12] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 266. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 273. | ZS23C08025 | [40] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 278. | ZS23C06030 | [5] | SCREW,Hex Socket Head, M6 x 30mm | KOB |
| 517. | YN30V00101S517 | [1] | HYDRAULIC VALVE | SMPOPPET |
| 518. | YN30V00101S518 | [1] | HYDRAULIC VALVE | SMPOPPET |
| 527. | YM30V00008S527 | [1] | SPRING | SM |
| 528. | YM30V00008S528 | [1] | SPRING | SM |
| 606. | LB30V00015F1 | [2] | VALVE PRESSURE RELIE | KOB |
| 973. | ZS23C14130 | [7] | CAPSCREW,Hex Socket Head, M14 x 130mm | KOBSCREW |
| 974. | ZS23C14130 | [2] | CAPSCREW,Hex Socket Head, M14 x 130mm | KOBSCREW |
| 977. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 978. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
