神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.359.AG) - CONTROL VALVE INSTALL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
194 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM64H01026P1 | [1] | BRACKET | KOB(CNH 87649340) |
| 2. | YB64H01030P1 | [1] | BRACKET | KOB(CNH 87394110) |
| 3. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOB(CNH 11118534) |
| 4. | ZS18C12045 | [3] | SCREW,Hex, M12 x 45mm | KOB(CNH 11113034) |
| 5. | ZW16H16000 | [4] | WASHER | KOB(CNH 71405003) |
| 6. | YM30V00013F1 | [1] | CONTROL VALVE | KOB |
| 7. | YN64H01392D1 | [3] | CAP | KOB(CNH 87643223) |
| 8. | YN64H01393D1 | [2] | CAP | KOB(CNH 87643224) |
| 9. | YN64H01391D1 | [7] | CAP | KOB(CNH 87643225) |
| 10. | ZW16P12000 | [3] | WASHER | KOB(CNH 14496731) |
