神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.600.BG) - PILOT VALVE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
304 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LQ30V00033F2 | [1] | HYDRAULIC VALVE | SMPilot, Start Serial: YQ13U5213 |
| 2. | 72209858 | [4] | PLUG | IMO(2436U1277S211) Superseded by part number: 2436U1277S211 |
| 4. | 72209860 | [4] | SEAL | IMOSeal (2436U1277S213) Superseded by part number: 2436U1277S213 |
| 5. | 72209824 | [4] | O-RING | IMO(ZD12P02000) Superseded by part number: ZD12P02000 |
| 6. | 72209861 | [2] | SEAT/SLOT | KOB(YT30V00008S216) Superseded by part number: YT30V00008S216 |
| 7. | YT30V00008S010 | [2] | SPRING SEAT | KOB |
| 8. | 72209862 | [4] | WASHER | IMO(2436U1277S217) Superseded by part number: 2436U1277S217 |
| 9. | LQ30V00033S218 | [4] | SPRING SEAT | KOB |
| 10. | LQ30V00033S221 | [4] | SPRING | KOB |
| 11. | LQ30V00033S241 | [2] | SPRING | KOB |
| 12. | LQ30V00033S242 | [2] | SPRING | KOB |
| 13. | LQ30V00033S246 | [2] | SPRING | KOB |
| 14. | LQ30V00033S247 | [2] | SPRING | KOB |
| 15. | 72209867 | [1] | FLEXIBLE JOINT | IMO(2436U2581S301) Superseded by part number: 2436U2581S301 |
| 16. | 72209868 | [1] | PLATE | IMO(YT30V00008S302) Superseded by part number: YT30V00008S302 |
| 17. | 72209869 | [1] | NUT | SM(YT30V00008S312) Superseded by part number: YT30V00008S312 |
| 18. | 72209870 | [1] | BOOT | IMOCover (YT30V00008S501) Superseded by part number: YT30V00008S501 |
