神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.738.AE) - HYD. LINE, BUCKET CYLINDER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
627 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM43H01013P1 | [1] | TUBE,1214, 81 mm L | KOB |
| 2. | YM43HU1005P1 | [1] | BAND | KOB |
| 3. | YM43HU1004P1 | [1] | BAND | KOB |
| 4. | YN43H01097P1 | [1] | CLAMP | KOB |
| 5. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 6. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 7. | ZD12P02600 | [1] | O-RING | KOB |
| 8. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 9. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOB |
| 10. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOB |
| 11. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOB |
| 12. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 13. | ZW16H10000 | [1] | WASHER | KOB |
