神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (39.103.AD[02]) - SLEWING RING, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
514 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM40F01003P1 | [1] | RACE | KOBRace, Outer (Not serviced - order upper assembly) |
| 2. | YM40F01004P1 | [1] | RACE | KOBRace, Inner (Not serviced - order upper assembly) |
| 3. | 2425T380 | [90] | BALL | KOB |
| 4. | LQ40F01009P1 | [90] | RETAINER | KOB |
| 5. | YN40F01019D7 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 6. | YN40F01019D8 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 7. | YN22T00194P1 | [1] | TYPE PLATE | KOB |
| 8. | 2420Z1036D3 | [2] | CLEVIS | KOB |
| 9. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
